| Model No. | WH7505UC |
| Input | USB-C/A |
| Output | RJ45 5000 |
| MbpsMaterial | Aluminum |
Model No. WH7505UC
USB A/C 3.2 to 5G Ethernet Adapter
Description
USB A/C 3.2 to 5Gbps Ethernet Adapter is a high performance and low expenditure solution. It enables a Fast Ethernet network connection capability for all desktops, notebook PC’s with standard USB port and USB-C/Thunderbolt 3 laptops. It resolves the trouble of the computer without Ethernet port that you can also connect computer to Ethernet through USB A or USB C 3.1 port easily.
5000Mbps Stunning Streaming
The 5Gigabit Ethernet Adapter supports high-speed broadband up to 5Gbps(5000Mbps), 5x faster than 1Gbps Gigabit Ethernet and backwards compatible with 10/100/1000/2500Mbps. The 5G Ethernet Adapter is ideal for professionals and hobbyists who need the highest possible data streaming speed, like high-efficiency pursers, online gamers, PC enthusiasts, overclockers, live streamers, and video content producers.
Improved Stability & Security
* Advanced Chipset--The outstanding RTL8157 chip ensures an ultra-fast, stable and secure data streaming.
* Robust Casing-- The aluminium case dissipates heat quicker and prevents the high-performance Gigabit Ethernet Adapter against over-heat issues. Plus, the aluminium case can resist more wear and tear and offer a longer lifespan.
* Tight Connections--Built with standard USB C and USB A double plug and RJ45 connectors, the USB C Network Adapter fits snugly to your devices and significantly improves stable data transfer.
Easy Installation & Portable
* Driver-free, plug & play on Mac OS, iOS.
* Integrated driver for Windows 11/10/8.1/7/Vista/XP. Open My Computer and click the driver files to install.
* Support Wake-on-Lan (WoL), Full-Duplex (FDX) and Half-Duplex (HDX) Ethernet, Auto Crossover Detection, IPv4/IPv6 protocols, IEEE 802.3/IEEE 802.3u/IEEE 802.3ab/IEEE 802.3az/IEEE 802.3bz(Energy Efficient Ethernet).
* Slim, compact and lightweight design makes this USB A/C 3.2 RJ45 Ethernet Connector portable to carry around. Ideal for travel use.
Features:
- Supports USB3.0/USB C 3.2 input and 5Gbps RJ45 output.
- Supports 10M /100M /1G /2.5G/5G bandwidth.
- Supports twisted pair crossover detection and auto-correction.
- USB bus power (no external power supply).
- Supports USB 3.2, 3.1, 3.0, 2.0 and 1.1.
- Support WOL(Wake-On-LAN), Full Duplex flow(10M/100M/1G/2.5G/5G Rate)
- Auto-Negotiation.
Supports Operating System for Computers:
- Windows: 7 / 8 / 8.1 / 10 /11/ Vista/ XP (32/64bit)
- Mac: macOS / Mac OS X 10.6 to 10.15 version
- Linux
Warm Reminder
* To realize 5Gbps data speed, please use CAT 6 or above Ethernet cable.
How to connect
·Connect the adapter directly to your computer or laptops
·Connect your Cat 6 network cable to a LAN or router
·No extra software drivers needed
·No external power required
Product Feature
|
Product Size |
71.0x26.3x17.9mm |
|
Weight |
39.5g |
|
Cable Length |
15cm |
|
Chipset |
RTL8157 |
|
Operating voltage / current consumption |
5V max. 900m A |
|
Compatibility |
USB/USB C port |
|
System requirements |
Windows 11 /10 /8/7 Mac OS 10.8 ≥ |
|
USB specification |
USB 3.2 Gen1 |
|
Operating Temperature |
0℃ to 40℃(35°F to 100°F) |
|
Operating Humidity |
20% RH to 80% RH |
Package content
1x USB A/C 3.2 5Gigabit Ethernet Adapter
1x Manual
